Model |
SWG-S10 |
||||
Monitor |
10.1-inch Monitor |
||||
Electronic Amplification |
1X-5X |
||||
Working Distance |
10cm～∞ |
||||
Bracket Size |
Base 230X150mm,column height 285mm,diameter 22mm |
||||
Sensor |
8.3 Million Pixels （Built in HD lens） |
||||
Output Method |
HDMI、Type-C |
||||
Sensor Size |
1/2.8 |
||||
Pixel Size |
1.45μm X 1.45μm |
||||
HDMI Resolution Ratio |
3840X2160 30fps/1920X1080 60fps (HDMI interface can connect to monitor or TV) |
||||
Photo |
3840X2160 JPG format |
||||
Video |
4K 30 FPS (38400 X 2160) MP4 format |
||||
Lens |
HD Lens |
||||
Focus Mode |
Support manual focusing (adjustable through the focusing knob and remote control) |
||||
Image Adjustment |
Exposure,Saturation,contrast,Sharpness,Black and,white,Horizontal/Vertical flip,Freeze,Picture Playback |
||||
Storage Mode |
U disk |
||||
Grid Line |
Supports 16 straight lines with adjustable color,thickness and position |
||||
Language |
English/Chinese/Arabic/Italian/Russian/Japanese/Spanish/French |
||||
Image comparison |
Support comparison of 2 images |
||||
Input Voltage |
AC100V-240V 12V/2A |
||||
Type-C |
PC Software（Support Photo,Video,Measurement） |
||||
LED Light Source |
60 LED light beads, with the brightness adjustable via the knob. |
||||
Working Distance |
WD (100mm) |
WD (150mm) |
WD (200mm) |
WD (250mm) |
WD (300mm) |
Field of view |
21X12mm |
33X19mm |
46X26mm |
56X33mm |
68X40mm |
Optical magnification |
10X |
6.5X |
4.6X |
3.8X |
3.1X |
Digital magnification |
50X |
33X |
23X |
19X |
16X |
