Model |
SWG-4K830WF |
|
Optical Magnification |
1X-28X |
|
Working Distance |
10cm～∞ |
|
Pixels |
8.3 Million Pixels Autofocus Microscope Camera (Built-in wide-angle lens) |
|
Output Method |
HDMI/USB |
|
Pixel Size |
1/2.8“ |
|
HDMI Resolution Ratio |
3840 X 2160 60FPS |
|
Photo Resolution Ratio |
3840X2160,(Photo can be Manually and Automatically Named file Name) |
|
HDMI Video Recording |
1080P 30 FPS (1920 X 1080) MP4 Format |
|
White Balance |
Auto/Manual |
|
Image Adjustment |
Exposure Value,Saturation,Brightness,Contrast,Definition,Anti Reflective,Black and White,Flip,Crosshair,Support Horizontal/Vertical Flip,Picture Playback,Supports Image Freezing |
|
Storage Mode |
U Disk Storage,Photo Taking,Video Recording and Measurement |
|
Cross Hair |
Support 100 Groups Cross Line,The Color Position is Adjustable |
|
Color Adjustment |
R、G、B |
|
USB3.0 |
By Connecting to a Computer via the USB3.0 Interface,the image software can Achieve Manual/Automatic Focusing |
|
Input Voltage |
AC100V—240V 12V |
|
Measuring Function |
Point Spacing,Point line Spacing,Line Spacing,Circle Center Distance,Arc, Circle,Angle Rectangle and Polygon Measurement,Calibration Function,Automatic Edge Searching. |
|
Language |
Chinese,English,Traditional Chinese |
|
(Amplification Scaling Ratio) |
FOV(10cm Working Distance) |
FOV(30cm Working Distance) |
1X |
171mmX92mm |
420mmX230mm |
2X |
89mmX50mm |
196mmX110mm |
3X |
71mmX40mm |
150mmX84mm |
4X |
60mmX33mm |
116mmX65mm |
5X |
52mmX29mm |
101mmX57mm |
14X |
24.3mmX13.5mm |
45.5mmX25mm |
28X |
12.2mmX7mm |
25mmX13.6mm |
