| Product model | SWG-3D6000 |
| Depth of Field Synthesis | Samples of Different heights can be Combined into a clear picture |
| Image overlay | Can be imported through drawing and display transparent background color on the screen Convenient product and overlay image alignment detection |
| Measuring Function | Between two Points,Point to line,three point circle,center distance,concentric circle, point to circle,line to circle,parallel line,Rectangle,angle,radian,polygon |
| Optical Magnification | 0.28-2X |
| Electronic Magnification | 10X-73X |
| Field of View | 4mm-28.57mm |
| Eyepiece | 0.4X |
| Objective Lens | 0.7X-5X Continuous Amplification |
| Working Distance | 100mm |
| Base Plate Size | 320mmx260mmx16mm, height 300mm |
| 2D/3D Manual Switch | The Working Distance Remains the Same,No Need to Refocus,After Adjusting the Center,the Center Remains the Same,360°Free Choice,Objective Lens Angle 45° |
| LED Light Source | 144 Lamp Beads,Inner Diameter 61mm,Input Voltage,AC100,240V,Maximum Output Power 4.5W,Voltage 12V |
| Pixel | 2 Million Pixels |
| Output Method | HDMI、Network Interface |
| Sensor | 2M/Sony |
| Sensor Size | 1/2＂CMOS |
| Resolution Ratio | 1920X1080 |
| Output Frame Rate | 60FPS |
| Pixel Size | 3.75μmX3.75μm |
| Storage Mode | U disk.Can Take Pictures,Measure |
| Image Adjustment | Brightness,Contrast,Saturation,Edge sharpening,anti flicker,HDR suppression of Strong light Modes |
| Color Adjustment | R、G、B |
| White Balance | Auto/Manual |
| Exposure | Auto/Manual |
| Mirror Configuration | Horizontal Mirror,Vertical Mirror |
| Reticle lines | 32 Groups Horizontal and vertical lines |
| Network interface | Provide Professional KOPPACE Image Software to support measurement and Photography |
| USB Interface | 2 USB Ports,1 Connected to USB Drive and 1 Connected to Mouse |
| language | Chinese,English,Traditional |
| Camera Interface | C Interface |
| Power Supply | AC100V-240V DC-12V |
| Display | 11.6 inches |
