Model |
SWG-W2700 |
Optical Magnification |
40X-1600X |
Electronic Amplification |
283X-7090X |
Observation Tube |
Hinge Trinocular,30 Degrees Inclined,360 Degrees Rotate
|
Eyepiece |
Wide-angle Eyepiece WF10X/20mm,WF16 |
Objective Lens |
Infinite Flat Field Achromatic Objective
|
Converter |
Four Holes Conversion |
Operating Platform |
Right Hand Low Hand Control of X and Y Directions Platform Area:160mmX142mm,Moving Range 76mmX52mm |
Coarse Micro Focusing Mechanism |
Low Hand Coarse Micro Coaxial Focusing Mechanism,Coarse Adjustment Stroke 22mm,
|
Condenser |
Abbe Condenser,N.A. = 1.25,Adjustable Center,With Variable Light bar and Filter Bracket |
Light Source |
Reflector Lamp Room,Single High Power 3W LED |
Power |
External Regulated Power Adapter, 100V-250V_AC50/60Hz DC5V/2A |
Trinocular Interface |
1X |
Pixel |
25 Million Pixels |
Output Method |
USB3.0 |
Sensor |
25M/SONY IMX511(C) |
Sensor Size |
1/2.3" (5.519x5.519) |
Resolution Frame Rate |
12@4928x4928，46@2464x2464，100@1648x1648 |
Pixel Size |
1.12μmx1.12μm |
Exposure Time |
0.013ms~15s |
Exposure |
Auto/Manual |
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
Color Rendering Technique |
Ultra Fine Color Engine |
Capture/Control SDK |
Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++,C#/VB.NET,Python,Java,DirectShow,Twain,etc); |
Shooting Mode |
Images and Videos |
Operating System |
Microsoft Windows /Vista / 7 /8 /10(32 & 64 bit) OS X (Mac OS X),Linux |
File Save |
Can Set File Name,Save Pictures With Time Format,Save Path Selection |
Image Adjustment |
Hue,Saturation,Brightness,Contrast,Sharpness,Color,Grayscale |
Measuring Function |
Point Spacing,Point Line Spacing,Line Spacing,Center Distance arc,circle, Angle,Rectangle,Polygon Measurement,
|
Camera Function |
Advanced software for Windows:
|
