| Product model | SWG-4KH3D |
| Focusing stroke | 200mm |
| Lens aperture | 50mm |
| Standing arm height | 330mm |
| Center distance | 150mm |
| Base size | 320mm*240mm |
| Magnification | 27X-173X |
| Field of view | 1.87 mm to 16.57 mm |
| Port | C interface |
| 3D imaging Angle | 30 ° |
| Working distance | 30mm |
| 3D rotation | Electric motor control; Automatic rotation, adjustable speed |
| LED light | Built-in LED light source (36 LED beads, 12V2.4W) |
| Pixel | 8.3 million pixels |
| Exportation | HDMI/ Gigabit network |
| Photographic resolution | 3840X 2160,7680 x 4320 |
| Video resolution | 3840X 2160 |
| Pixel size | 2.0 mu mX2.0 microns |
| Sensor size | 1/1.8 |
| Exposure mode | Line-by-line exposure |
| Output frame rate | 60 frames |
| Output color | Chroma |
| Camera function | The newly developed version of the V3 measurement system is built in, once again improving image clarity; |
| 4K output image, real-time frame rate 60FPS; | |
| New functions: custom interface editing, custom template editing, Dxf import template, file management, measurement data export and other functions; | |
| SONY high-performance photosensitive chip Low noise, high sensitivity, true color; | |
| Dual-core 2 * A73 1.6GHz + 2 * A53 1.2GHz; Multi-block 4GB DDR4 + 8GB eMMC; | |
| Equipped with USB3.0, gigabit network interface; | |
| Hd shooting, recording, preview and playback; | |
| Built-in automatic edge finding function, improve the measurement effect; | |
| Support U disk storage function, you can connect the mouse; | |
| Display | 27 inches |
